Specifications:
Model | HZX-ARRB56HD-4K |
Camera | |
Image Sensor | 1/2.8" Sony IMX415 CMOS |
Chipset | FH8556 |
Effective Pixels | 3840(H)×2560 (V) |
Video Resolution | AHD/TVI/CVI:15fps@2560×1944P,12.5fps@2560×1944P(PAL), CVBS:960H, adjustable |
Electronic Shutter | AUTO, 1/25 - 1/50,000s |
Min. Illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on |
Video System | PAL/NTSC |
Video Output | 1 channel, HDCVI / HDTVI/AHD/CVBS , adjustable |
Video Switch | DIP switch |
Day/Night | Auto/Color/(B/W)/EXT |
White Balance | ATW/Manual |
DNR | 2D/3D NR |
OSD Menu | Multiple languages OSD menu control up the coaxial cable (UTC) |
IR Led | |
IR Led | 4pcs Array IR Leds |
IR Distance | 30-35 M |
Lens | |
Focal length | 2.8-12mm manual varifocal lens |
General | |
Power Supply | 12 VDC ± 10% |
Power Consumption | < 5 W |
Operating Temp. | -20℃-(+60)℃, 10%-90%RH |
