Specifications:
Model | HZX-HD2408H-Q3 |
Video/Audio Input | |
Analog Video Input | 8-ch, BNC |
IP Video Input | 4-ch(only IP up to 12ch), each channel up to 8MP |
Supported Analog Camera Types | Support AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support TVI input: 8MP@15fps 5MP@20fps 4MP@30fps |
1080P@30fps 720P@30fps Support CVI input: 8MP@15fps 5MP@25fps 4MP@30fps 1080P@30fps 720P@30fps Support CVBS input | |
Audio Input | 1-ch, RCA |
Audio Compression |
G.711U |
Video/Audio Output | |
CVBS Output | 1-ch, BNC |
VGA Output | 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
HDMI Output | 3840 x 2160/30Hz, 1920x1080p/60Hz, 1920x1080p/50Hz, 1600x1200/60Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
Audio Output | 1-ch, RCA |
Synchronous Playback | 8 |
Live view display | HDMI/VGA: 1/4/6/8/9/16 |
Two-way Audio | 1-ch, RCA |
Snapshot | |
FTP/Schedule/E vent Snapshot | 8-ch snapshot, up to 704*576 resolution |
Network | |
Incoming Bandwidth | 40Mbps (Up to 56Mbps after all analog channel conversion) |
Outgoing Bandwidth | 64Mbps |
Remote Users | 128 |
Protocols | TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP |
Browser | IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows |
Encoding | |
Recording Resolution | 8MP Lite/5MP Lite/4MP Lite /1080P/720P/CIF | |
Recording Frame Rate | Main stream | Sub stream |
8MP Lite@8fps | D1@8fps | |
5MP Lite @12fps | D1@12fps | |
4MP Lite@15fps | D1@15fps | |
1080P@15fps | D1@15fps | |
720p@30fps | D1@30fps | |
Audio Sample Rate | 8KHz,16 bit per channel | |
Audio Bit Rate | 64Kbps per channel | |
Decoding | ||
Capability | Analog: 8 x 8MP Lite@8, 8x 5MP Lite@12, 8x 4MP Lite@15, 8x 1080P@15 IP: 1 x 8MP@30, 2 x 4MP@30, 4 x 1080P@30 | |
Hard Disk | ||
SATA | 1 SATA interface | |
Capacity | Up to 8TB for each HDD (The maximum HDD capacity varies with environment temperature) | |
Smart Alarm | ||
VCA Detection | Ultra Motion Detection(UMD) for analog:8-ch | |
VCA Search | Behavior Search | |
General Alarm | ||
General Alarm | Motion detection | |
Alert Alarm | IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal | |
External Interface | ||
Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet Interface | |
USB Interface | Rear panel : 2 x USB2.0 | |
RS485 | 1 | |
Alarm In | 4-ch | |
Alarm Out | 1-ch | |
General | ||
Power Supply | 12V DC Power Consumption: ≤ 10 W( without HDD ) | |
Working Environment | - 10°C ~ + 55°C ( +14°F ~ +131°F ), Humidity ≤ 90% RH(non-condensing) | |
Dimensions(W× D×H) | 260mm ×226mm× 47mm (10.2" × 8.9"×1.8") |
Weight ( without HDD ) | ≤1.1 Kg ( 2.42lb ) |
Certification | |
Certification | UL /CE /FCC /RoHS /WEEE |
