Specifications:
| Model | HZX-N1164G | |
| System | OS | Embedded Linux |
| Video | Network Input | 64 CH IPC input |
| Incoming Bandwidth | 320Mbps | |
| Outgoing Bandwidth | 320Mbps | |
| Network Input Resolution | 12MP/ 8MP/ 6MP/5MP/4MP/3MP/ 1080P/ 1280 × 1024/960P/ 720P/960H/D1/CIF | |
| Output | HDMI 1 : 3840 × 2160@60fps / 3840 × 2160@30fps / 1920 × 1080 /1280×1024 / 1024 × 768 HDMI 2: 1920 × 1080/ 1280×1024 / 1024 × 768 VGA × 1: 1920 × 1080 / 1280×1024 / 1024 × 768 | |
| Compression | H.265S/H.265+/H.265/H.264 | |
| Multi-screen display | 1/4/6/8/9/ 13/ 16/25/32/36/64 | |
| Audio | Network Input | 64 CH IPC audio input |
| 2-way Audio | RCA × 1 | |
| Local Output | RCA × 1 | |
| Compression | G.711(U/A) | |
| Record | Record Stream | Dual stream recording |
| Resolution | 12MP@20fps; 8MP/ 6MP/5MP/4MP/3MP/ 1080P/ 1280 × 1024/ 960P/ 720P/960H/D1/CIF@30fps(NTSC)/25fps(PAL) | |
| Mode | Manual/timed/motion/sensor/POS/AI recording | |
| Playback | Simultaneous Playback | Max 16 CH |
| Search | Time slice / time / event / tag / smart search | |
| Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refers to different record events | |
| Function | Play, pause , FF, FB, digital zoom , etc . | |
| Decoding Capability | Live View/Playback | 1CH 12MP / 4 CH 5MP / 9 CH 720P/ 16CH 720P |
| Alarm | Mode | Manual , sensor, motion , exception , smart events |
| Input | 8 CH local alarm input; supports IPC alarm input | |
| Output | 4 CH | |
| Triggering | Record , snapshot, buzzer, preset , e-mail , etc . | |
| Video Structure Analysis | Human/Vehicle Classification | Yes |
| Other Functions | Fisheye | Supports fisheye dewarping via Web Client and mobile APP |
| Plate Recognition | Yes | |
| Network | Interface | RJ 45 10 / 100 / 1000 Mbps × 2 |
| Protocol | TCP / IP, PPPoE , DHCP, DNS , DDNS , UPnP, NTP, SMTP, HTTP, HTTPs , 802 . 1x , ONVIF, etc . | |
| Client Connection | Max .20 users access | |
| Mobile Device | OS | iOS , Andriod |
| Storage | HDD Interface | SATA×8 , up to 8TB per HDD; E-SATA×2 |
| RAID | RAID0 , RAID1 , RAID5 , RAID6 , RAID10 | |
| Backup | Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes | |
| Port | USB | USB2 .0 × 2 , USB3 .0 × 1 |
| RS 485 | Yes (full-duplex) ; connectors for PTZ and keyboard | |
| Remote Controller | Yes | |
| Others | Power Supply | ATX 250W |
| Consumption | ≤ 30W ( without HDD ) | |
| Dimensions(mm) | 445 × 436 × 90 (W × D × H) | |
| Working Environment | - 10 ～ 50 ℃ , 10% ～ 90% humidity | |
| Certificate | CE, FCC | |
| Environmental Protection | Complies with Directive EU RoHS , REACH and WEEE | |
