Features:

●1/2.8" Sony IMX307 CMOS sensor

● Full HD resolution 1920 x 1080P

● Ultra low illumination 0.001Lux

● Day/ Night (ICR), AWB, AGC, BLC, 2D/3D-DNR, IR-CUT

● D-WDR, Motion Detection, Privacy Mask, Mirror

● RTSP and Onvif 17.06 compatible

● H.265/ H.264 dual-stream media server

● Easy-to-use P2P Cloud service

● Multi web browser, PC Client, mobile APP remote access

● With built in microphone and SD card slot

● Lightning protection 4000V

● Strong water-proof housing, IP67

● 24PCS SMD IR Leds , IR distance:40-50M

● 2.8- 12mm/VF

Description

Specifications:

Model

HZX-IPB54-2MP

Camera

Image Sensor

1/2.8" SONY IMX307 CMOS

Effective Pixels

1920 (H) × 1080 (V)

Electronic Shutter

AUTO, 1/25s ~ 1/ 100000s

Min. Illumination

0.001Lux@F1.2(AGC ON), 0Lux IR on

Day/ Night

Auto/Color/(B/W)/Timing

WDR

Digital WDR/ HDR(>120dB)

White Balance

Auto/ Indoor/Outdoor

BLC

Support

DNR

2D/3D DNR

Other

Human body detection, Motion Detection, Privacy Mask, Mirror, flip

Encode

Embedded Solution

SSC335

Video Standard

H.264/H.265

Video Resolution

Main stream: 1080P@25/30fps , 720P@30fps

Sub stream: D1/VGA/360P@30fps

Video Bitrates

32Kbps - 5MbpsVBR/CBR

Audio Standard

G.711-u/G.711-a

OSD Overlay

Title and Time overlay

Leds

Leds

20PCS SMD IR LedS

IR Distance

30-40 M

Lens

Focal length

2.8- 12mm/VF

Functions

Audio/SD card slot (support maximum 256GB SD card )

Network Services

Protocol

HTTP/RTSP/FTP/NFS/SMTP/DHCP/NTP, etc.

P2P

Yes

Web

IE , Firefox, etc.

Media

CMS, AndroidIOS

ONVIF

17.06 compatible

General

Network Port

1-RJ45, 100Mbps, POE

Power Supply

12 VDC ± 10%

Power Consumption

< 8 W

Operating Temp.

-30-(+60), 10%-90%RH
